Product Overview
BBMU-BMD is designed for ultrasonic bone densitometry systems. Frequency, active area, and transducer configuration can be selected for radial, calcaneal, or finger-bone measurements.
Radial, calcaneal, and finger configurations support different measurement sites, instrument structures, and acoustic-channel designs.
Applications
- Radial bone density measurement
- Calcaneal bone density measurement
- Finger-bone density measurement
Technical Specifications
| Parameter | Specification |
|---|---|
| Radial configuration | 1 MHz or 1.25 MHz; 4 elements |
| Calcaneal configuration | 500 kHz; active area Φ20–Φ25 mm |
| Broadband calcaneal configuration | 500 kHz; 85% relative bandwidth |
| Finger configuration | 200 kHz; active area Φ10 mm |
Customization Options
- Measurement site
- Operating frequency
- Element count
- Active area
- Housing dimensions
